HPMC co-rotating triple screw extruder for polymer compounding and recycling

Corotating Triple Screw Extruder For Compounding & Recycling

HPMC Triple Screw Extruders provide high-output compounding and recycling solutions with excellent mixing, high filler loading capability, and production capacities up to 1500 Kg/hr.

Product Overview

Co-Rotating Triple Screw Extruder - For Compounding & Recycling

HPMC Triple Screw Extruders are specially engineered for high-filler compounding, masterbatch production, and recycling applications. Delivering outputs up to 1500 Kg/hr, they provide exceptional mixing, plasticization, and processing efficiency for demanding polymer formulations.

Applications

• Direct Compounding
• PVC Cable Compounds
• Film & Sheet Extrusion
• Injection Molding
• Compression Molding
• Recycling

Key Features

• High Precision Gearbox
• Modular Screw Design
• Reliable Lubrication System
• Die Face Cutter
• Vibratory Sieve
• Smooth Material Feeding

High Filler Capability

• High Filler Compounding
• Masterbatch Production
• Engineering Plastics
• Polymer Alloys
• Wood Fiber Composites
• Consistent Product Quality

Machine Models

Technical Specifications

MACHINE MODELS	20	30	35	50	65	72	92
Screw Diameter (mm)	21.7	30	35.6	50.5	62.4	71.2	91
Max Rotary Speed (RPM)	600	400	600	500/600	400/500	400/500	400/500
Main Motor Power (kW)	4	11	11/15	37/45	55/75	90/110	220/250
L/D Ratio	32-40	28-48	32-48	32-48	32-48	32-48	32-40
Capacity (kg/h)	2-10	5-30	10-80	20-150	100-300	300-600	600-1000

Frequently Asked Questions

Everything About Our Corotating Triple Screw Extruder

Find answers to common questions about PVC pipe extrusion, machine specifications, applications, output capacity, installation, and maintenance.

Expert Support

Quick answers before you enquire

10 of 75 FAQs

A Co-Rotating Triple Screw Extruder is an advanced polymer processing machine designed for high-performance compounding, masterbatch production, engineering plastics, recycling, and high-filler applications with superior mixing efficiency.

Three co-rotating screws work together to melt, mix, plasticize, and convey polymer materials, providing better dispersion, higher throughput, and improved product consistency than conventional extrusion systems.

A Triple Screw Extruder offers higher mixing efficiency, improved filler dispersion, greater output, enhanced plasticization, and better process stability compared to a conventional Twin Screw Extruder.

Triple Screw technology provides superior mixing, higher productivity, improved material dispersion, reduced processing time, and better performance for demanding compounding applications.

It is used for polymer compounding, engineering plastics, masterbatch production, filler modification, recycling, PVC compounds, polymer alloys, and specialty plastic formulations.

The machine processes PP, PE, ABS, PVC, PET, PA, PC, EVA, TPE, TPU, engineering plastics, recycled polymers, biodegradable plastics, and specialty compounds.

Yes. It efficiently processes recycled plastics into high-quality pellets while maintaining excellent dispersion and material consistency.

Yes. Triple Screw Extruders provide outstanding pigment dispersion for producing premium-quality color masterbatches.

Yes. It is suitable for UV, antioxidant, anti-static, flame-retardant, anti-block, and other additive masterbatches.

Yes. The machine is specifically designed for engineering plastic compounding with excellent mixing and temperature control.

📞

Discuss Your Requirements with Our Experts

Tell HPMC about your material, required output and compounding application. The team can review your requirements and advise on an appropriate machine configuration.

☎️
